SMD3528 LED Strip Lights
HST-SMD3528-120 120 LEDs/m SMD3528 LED Strip Light
HST-SMD3528-120 is an 8mm PCB SMD3528 LED strip with 120 LEDs/m density, 9.6W/m power, and CRI 80+ color rendering. Available in 12V and 24V DC with IP20, IP65, IP67, and optional IP68 versions, it is suitable for aluminum profiles, cabinet lighting, furniture lighting, retail displays, and commercial lighting projects. OEM/ODM customization is available for voltage, CCT, IP structure, cable, connector, and packaging.
Specifications
- Model
- HST-SMD3825-120
- LED Type
- SMD3528
- LED Density
- 120 LEDs/m
- PCB Width
- 8 mm
- Voltage
- 12V / 24V DC
- Power
- 9.6 W/m
- Color Temperature
- 2700K / 3000K / 4000K / 6000K
- CRI
- Ra 80+
- IP Rating
- IP20 Standard / IP65 / IP67 / IP68 Optional
- Cutting Unit
- 25 mm (12V) / 50 mm (24V)
HST-SMD3528-120 120 LEDs/m SMD3528 LED Strip Light
HST-SMD3528-120 is an 8mm PCB SMD3528 LED strip featuring 120 LEDs/m density and 9.6W/m power consumption.
Designed for cabinet, furniture, retail display and general linear lighting applications, this LED strip provides reliable and consistent illumination in a compact format.
Available in 12V and 24V DC, with multiple color temperature and IP protection options, HST-SMD3528-120 also supports OEM/ODM customization for PCB, voltage, CCT, CRI, cable, connector, strip length and packaging.
Key Specifications
Parameter | Value |
|---|---|
Model | HST-SMD3528-120 |
LED Type | SMD3528 |
LED Density | 120 LEDs/m |
PCB Width | 8 mm |
Voltage | 12V / 24V DC |
Power | 9.6 W/m |
Color Temperature | 2700K / 3000K / 4000K / 6000K |
CRI | Ra 80+ |
IP Rating | IP20 Standard / IP65 / IP67 / IP68 Optional |
Cutting Unit | 25 mm (12V) / 50 mm (24V) |
Beam Angle | 120° |
Lifespan | 50,000 hours |
Selection Tip
For longer installation projects, the 24V version is generally recommended to help reduce current and voltage drop.
For outdoor or wet-area applications, select the appropriate waterproof version according to the actual installation environment.
Why Choose HST-SMD3528-120 SMD LED Strip Light
Compact SMD3528 LED Package
The compact SMD3528 LED package makes this strip suitable for applications where installation space is limited, including cabinets, furniture, shelves and display structures.
120 LEDs/m Balanced Density
The 120 LEDs/m configuration provides consistent illumination for general linear lighting and decorative lighting applications.
8mm PCB Design
The slim 8mm PCB width is compatible with many common LED aluminum profiles and compact lighting installations.
12V and 24V Options
Two voltage options allow customers to select the suitable version according to installation length, cutting requirements and power distribution design.
CRI 80+ Color Rendering
CRI 80+ provides suitable color performance for general residential, retail, hospitality and decorative lighting applications.
Multiple IP Protection Options
Available in IP20, IP65, IP67 and optional IP68 versions for indoor, damp and outdoor lighting environments.
OEM / ODM Customization Support
HST Light supports project-based customization including PCB width, voltage, CCT, CRI, power, strip length, waterproof structure, cables, connectors and packaging.
Typical Applications
HST-SMD3528-120 is suitable for:
- Cabinet lighting
- Furniture lighting
- Shelf lighting
- Retail display lighting
- Aluminum profile lighting
- Residential decorative lighting
- Hotel and hospitality lighting
- Commercial interior lighting
- Cove and concealed lighting
- General linear lighting
Quality & Trust
HST Light SMD LED strips are manufactured under controlled production and quality inspection procedures.
Each production batch can be checked for:
- Appearance
- Electrical performance
- Power consumption
- LED function
- Brightness consistency
- Color consistency
- Cable and connector configuration
- Waterproof construction for applicable versions
For customized or project-specific products, sample evaluation is recommended before mass production.
CE and RoHS compliance documents are available according to customer requirements.
Request a Quote or Sample
Need HST-SMD3528-120 for Your Lighting Project?
Please send us your required specifications, application details and estimated quantity.
For a faster quotation, please provide:
- Required voltage
- Color temperature
- CRI requirement
- Required strip length
- Order quantity
- IP rating
- Installation environment
- Cable length
- Connector requirement
- Packaging requirement
Our team can recommend a suitable SMD3528 LED strip configuration according to your project requirements.
Contact HST Light for pricing, samples or customized project support.
OEM / Customization
OEM & ODM SMD3528 LED Strip Solutions
HST Light provides OEM and ODM customization services for distributors, wholesalers, contractors, lighting brands and project customers.
Customization options can include:
- PCB: PCB width and project-specific PCB design
- Voltage: 12V / 24V and customized voltage configurations
- LED Density: LED quantity according to product requirements
- Power: Power adjustment according to application requirements
- CCT: Color temperature customization
- CRI: CRI options according to project requirements
- Length: Custom strip and cable lengths
- Waterproof: IP protection according to installation environment
- Connectors: Connector type and connection method
- Cable: Cable type, outlet direction and cable length
- Packaging: OEM labels, reels, cartons and customized packaging
For non-standard specifications, HST Light can arrange sample development and testing before mass production to verify the final product configuration.
FAQ
Q1: Can I request HST-SMD3528-120 samples before bulk production?
Yes. Samples can be provided for testing and evaluation before mass production.
Customers can verify:
- Lighting performance
- Color consistency
- Electrical specifications
- Installation compatibility
- Cable and connector configuration
For customized specifications, sample approval is recommended before bulk production.
Q2: What customization options are available for SMD3528 LED strips?
HST Light supports customization based on project requirements, including:
- PCB width
- LED density
- Voltage
- Power consumption
- Color temperature
- CRI
- Strip length
- Connectors
- Cable length
- Waterproof solutions
- Packaging and labeling
Please provide your required specifications and application details for evaluation.
Q3: What is the recommended running length of HST-SMD3528-120?
The recommended running length depends on several factors, including:
- Working voltage
- Power consumption
- PCB resistance
- Cable size
- Installation length
- Power-feed position
- Installation method
For longer installations, the 24V version is generally preferred because it operates at lower current for the same power level and can help reduce voltage drop.
For project-specific lengths, HST Light can help evaluate the power-feed and wiring configuration before production.
Q4: What applications are suitable for HST-SMD3528-120 LED strip?
HST-SMD3528-120 is suitable for:
- Cabinet lighting
- Furniture lighting
- Shelf lighting
- Retail display lighting
- Aluminum profile lighting
- Hospitality projects
- Residential decorative lighting
- Commercial lighting applications
- Cove lighting
- General linear lighting
Q5: What is the difference between SMD3528 LED strip and COB LED strip?
SMD3528 LED strips use individual LED packages mounted on a PCB and are suitable for compact, flexible and cost-effective lighting applications.
COB LED strips use chip-on-board technology to create a more continuous, dot-free lighting effect.
The suitable choice depends on the required lighting effect, installation space, project specification and budget.
